SGS Multi Wire Rod Drawing Equipment Copper RBD Machine

Product Details

Place of Origin: China

Brand Name: Wiremac

Certification: SGS

Model Number: DLT- 400A2

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: Nude Packing or Wooden Case

Delivery Time: 30-50 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 10 Set/Month

Get Best Price
Product Details
High Light:

SGS Wire Rod Drawing Machine

,

Multimode Wire Rod Drawing Machine

,

5.5m Rod Drawing Machine

Inlet Wire:
8 Mm
Outlet Wire:
2.52 Mm - 3.0 Mm
Die No.:
8
Max Line Speed:
600 M/min
Die Dimension:
55 X 35
Main Motor Power:
132 KW (AC)
Required Voltage:
380V - 480V AC 50Hz
Dimension:
L12 X W4.5 X H5.5 M
Weight:
10 MT
Warranty:
1 Year
Quality:
Europe, US Standard
Color:
Blue Or Customized
Inlet Wire:
8 Mm
Outlet Wire:
2.52 Mm - 3.0 Mm
Die No.:
8
Max Line Speed:
600 M/min
Die Dimension:
55 X 35
Main Motor Power:
132 KW (AC)
Required Voltage:
380V - 480V AC 50Hz
Dimension:
L12 X W4.5 X H5.5 M
Weight:
10 MT
Warranty:
1 Year
Quality:
Europe, US Standard
Color:
Blue Or Customized
Product Description

SGS Multi Wire Rod Drawing Equipment Copper RBD Machine

Introduction

In order to ensure the smooth operation of wire on the contact wheel, good contact and no spark (spark will damage the surface quality of wire), the diameter of contact wheel shall be more than 100 times larger than that of wire; Zqa19-4 with good conductivity and thermal conductivity is selected as the material of the contact wheel body, while the annealed ring material in contact with the wire rod can reduce the wire rod surface damage caused by wire rod ignition and annealed ring wear after many experiments, considering its comprehensive performance indexes such as wear resistance, conductivity and arc extinguishing at 550 ℃.

In the main annealing section, the temperature of the wire is above 500 ℃. In order to prevent the oxidation of the wire, it is necessary to separate the high-temperature wire from the air with shielding gas. Therefore, reliable sealing structure shall be adopted for the conductor path and contact wheel of the main annealing section, and the inlet, exhaust and drain of protective gas shall be reasonably configured to prevent the entry of external air and reduce the leakage of protective gas. During continuous operation, only a small amount of protective gas needs to be added to the protective tank in the annealing section to prevent high-temperature oxidation of the wire rod, which is conducive to ensuring the product quality of the wire rod and reducing the amount of protective gas.

Technical Parameters



Item Specs
Input wire diameter 8 mm
Output wire diameter 2.52 - 3.0 mm
Max die passes 8
Max line speed 600 m/min
Main motor power 132 kw
Capacity of the accumulator 7 m
800 Power of motor for Drop Coiler

11KW(AC motor)

Drop coiler wheel size

φ800 mm

Maximum drop weight

2200 KG

Annealing voltage Max 65V DC
Anneal unit power 350 KVA
Annealing wheel diameter

φ 450

Total equipment power

450 KW

Power supply

400V AC 50HZ

Brake method Air disk type
Dies changing method Fast type


SGS Multi Wire Rod Drawing Equipment Copper RBD Machine 0



Our Company



Dongguan Wiremac Machinery Equipment Co., Ltd. Is located in Houjie Town, a famous historic town in China. Our company is a wire and cable equipment manufacturer integrating R&D, processing, assembly, commissioning and after-sales.



The company is committed to copper wire, copper clad steel, copper clad aluminum and other metal wire deep processing and research, with a variety of high quality machines: micro wire drawing machine, fine wire drawing machine, fine wire drawing machine with continuous annealing, medium fine wire drawing machine, intermediate wire drawing machine, intermediate RBD wire drawing machine and copper rod breakdown machine.



Our company provides a complete set of wire processing solutions for customers, but also customize and design non-standard special equipment according to the requirements of customers.



Our company upholds the spirit of “Honesty-based, Quality-based” enterprise, and continue to research and develop innovation and development, with professional skills and standardized pragmatic management, in line with the “High-quality and High-efficiency” business philosophy, from the overall planning, staff training, installation and commissioning, after-sales service, to provide customers with better and more satisfactory products and service.



SGS Multi Wire Rod Drawing Equipment Copper RBD Machine 1



Our Workshop



SGS Multi Wire Rod Drawing Equipment Copper RBD Machine 2SGS Multi Wire Rod Drawing Equipment Copper RBD Machine 3SGS Multi Wire Rod Drawing Equipment Copper RBD Machine 4



FAQ



1. Q: Are you manufacturer or trading company?
A: We are a manufacturer.



2. Q: What info you need before you make the proposal?
A: The input & output wire diameter, spool size, application, 3 phase voltage & frequency, annealing or not, and your other requirement.

3. Q: How can I trust you and make a payment to you?
A: (1) We are an audited supplier by international SGS, with its certificate. They approve that we are an original manufacturer and meet their standard.

(2) We are a member of Made in China, who is always responsible for all customers.

(3) Please visit us and check our factory by video, and request necessary documents from us.



4. Q: I have no experience buying something abroad. What can I do?
A: We will guide and show you how to do the importation, you can also seek help from your local agency.



5. Q: Do you provide installing and debugging overseas?
A: Overseas machine installation and worker training services are available.

6. Q: Can you make the machine according to my design or prototype?
A: Yes, we have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us.

7. Q: How does your factory do regarding quality control?
A: There is zero tolerance to poor quality. Quality control complies with SGS & ISO 9001. Every machine has to past testing and trial running before it's packed for shipment.

8. Q: How can I trust you that machines pasted testing and trial running before shipping?
A: 1) We record the testing videos for you, and every necessary photos for you.
2) We welcome you to visit us and test machine by yourself in our factory.

9. Q: What about our after-sale service?
A: We provide technical support on line as well as overseas services by skillful technicians.

10. Q: What should I do if I just start a new business?
A: Contact us immediately, we provide free consultant pre-sales service. Also we can help you with material purchase, worker training, etc.

11. Q: Can I visit you factory to check machines on-site? What Should I bring when I visit your factory?
A: We are manufacturer, and welcome customers to visit us. For special product design, you are suggested to bring some samples, you can test it with our machines on-site.



12. Q: Can I use my own logo?
A: No problem, please inform us.
