Product Details
Place of Origin: China
Brand Name: Wiremac
Certification: /
Model Number: 1250mm
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD 40000-80000 Unit Price
Packaging Details: /
Delivery Time: 45 working days
Payment Terms: T/T
Supply Ability: 50 sets per month
Name: |
Arch Type Stranding Machine |
Color: |
Customer Requirement |
Warranty: |
1 Year |
Name: |
Arch Type Stranding Machine |
Color: |
Customer Requirement |
Warranty: |
1 Year |
Φ1250mm PLC High speed bunching machine
Oil Pump Lifting Electromagnetic Brake 380V 1250mm PLC High Speed Double Twist Bunching Machine
Application:
| Inlet wire dia |
Copper MIN 0.5-2.5mm AL 0.8-3.0mm |
Cross sectional area | Max.50mm² |
| Lay length | 40mm-400mm(Can be enlarged on request) | Operation direction | “S” or “Z” |
| Take up spool size | Φ1250mm | Max.rotating speed | Max.600RPM/min(1200t/min) |
| Motor | 380V-30KW | Reel lifting | Oil Pump Lifting |
| Painting | customer specified |
SIEMENS PLC system+Taiwan Weinview touch screen+Weizheng magnetic poeder
|
|
Feature:
1. The speed is high, the tension is constant from empty to full, PLC automatically tracks and adjusts the tension, Weizheng magnetic powder takes up the wire, the tension is uniform, the quality of the strand is excellent, the whole machine is driven by a synchronous belt, and the twist is replaced by changing the pitch gear. At the same time, the machine can adjust the tension without stopping the machine, and the operation is simple.
2. The main engine is lubricated by oil and cooled by natural circulation, which effectively prolongs the life of the main shaft bearing.
3. The bearings of the whole machine are made of well-known brands, and the bow belt is made of new materials with good flexibility. It can avoid stock jumping caused by vibration during high-speed operation. The frequency converter, PLC, magnetic powder clutch, electromagnetic brake, and hydraulic jack are all made of well-known brands. Reduce failure rate and maintenance cost.
Pls feel free to contact us for more details,pics and videos.
