Φ800mm PLC High speed bunching machine double twister for BV wire making machine good price core wire strander equipment

Application

Suitable for copper wire stranding of Power cable,Lan cable,Automatic cables,Electrical wire,Date cable,Earphone cables etc.Φ800mm PLC High speed bunching machine double twister for BV wire making machine good price core wire strander equipment

Specification

1.Inlet wire dia:Φ0.29-Φ1.0mm

2. Bunched wire size:Max 2.5-16.0mm2

3. Lay length: 22.51-152.32mm(adjustable according to customer requirement)

4.Operation direction:“S” or “Z”

5. Take up spool size:Φ800mm

6. Max.rotating speed:Max.1200RPM/min(2400t/min)

7.Motor:15HP AC motor+frequency converter

8. Tension control:take up tension is controlled by magnetic powder clutch,PLC follows up and regulates tension, constant tension

9. Brake mode:Electromagnetic brake

10. Operation type:push button

11. Bobbin shifting:Manual hydraulic lifting

12. Traversing method:Rolling wire with ring drive units, row pitch and breadth are adjustable

13. Protection:Automatically brake/stop

1) Wire inside and outside is broken

2) The preset length is arrived

14. Touch screen method:Touch screen+ Siemens PLC+ Magnetic powder clutch, ensure constant tension from empty to full bobbin
