Product Details
Place of Origin: China
Brand Name: Wiremac
Certification: /
Model Number: PY-Φ300mm
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD8500-12000 Unit Price
Packaging Details: Machine dimension:L2100mm*W1500mm*H1150mm
Delivery Time: 45 working days
Payment Terms: T/T
Supply Ability: 50 sets per month
Brand: |
Wiremac |
Name: |
Φ300mm High Speed Bunching Machine |
Location: |
Guangdong Province,China. |
Wanrranty: |
1 Year |
Brand: |
Wiremac |
Name: |
Φ300mm High Speed Bunching Machine |
Location: |
Guangdong Province,China. |
Wanrranty: |
1 Year |
Application
Suitable for copper wire stranding of Power cable,Lan cable,Automatic cable,Electrical wire,Date cable,Earphone cable etc.Φ300mm high speed bunching machine
Specification
1.Inlet wire diameter:Φ0.04-Φ0.28mm
2.Bunched wire size:0.035mm-1.0mm²
3.Pitch: 2.95-58.5mm(adjustable according to customer requirement)
4.Operation direction:“S” or “Z”
5.Take up spool size:Φ300mm
6.Maximumrotating speed:3000RPM/minute
7.Motor:5HP AC motor+frequency converter
8.Tension control:Mechanism friction
9.Protection:Automatically brake/stop
1)Wire inside and outside is broken
2) The preset meter length is arrived
10.Brake mode:Electromagnetic brake
11.Traverse method:Rolling wire with ring drive units, row pitch and breadth are adjustable
12.Operation type:push button
13.Bobbin shifting:Manual hydraulic lifting
Pls feel free to contact us for more details,pics and videos.
