Φ300mm high speed bunching machine for super fine copper wire cable conductor making machine wire buncher

Product Details

Place of Origin: China

Brand Name: Wiremac

Certification: /

Model Number: PY-Φ300mm

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD5000-10000 Unit Price

Packaging Details: Machine dimension:L1970mm*W920mm*H1030mm

Delivery Time: 45 working days

Payment Terms: T/T

Supply Ability: 50 sets per month

Get Best Price
Product Details
High Light:
Inlet Wire Dia:
Φ0.03-Φ0.10mm..
Bunched Wire Size:
0.035-0.45mm²..
Take Up Spool Size:
Φ300mm..
Operation Direction:
“S” Or “Z”..
Max.rotating Speed:
Max.3000RPM/min..
Motor:
3HP..
Color:
Can Be Customized..
Inlet Wire Dia:
Φ0.03-Φ0.10mm..
Bunched Wire Size:
0.035-0.45mm²..
Take Up Spool Size:
Φ300mm..
Operation Direction:
“S” Or “Z”..
Max.rotating Speed:
Max.3000RPM/min..
Motor:
3HP..
Color:
Can Be Customized..
Product Description

Application

Suitable for copper wire stranding of Power cable,Lan cable,Automatic cable,Electrical wire,Date cable,Earphone cable etc.Φ300mm high speed bunching machine for super fine copper wire cable conductor making machine wire buncher

Specification

1.Inlet copper wire diameter:Φ0.03mm-Φ0.10mm

2.Stranded wire size:0.035-0.45mm²

3.Lay length: 1.27mm-12.55mm(adjustable according to customer requirement)

4.Operation directions:“S” or “Z”

5.Take up spool size:Φ300mm

6.Max.rotating speed:Max.3000RPM/min

7.Motor:3 HP

8.Tension control:By mechanism friction

9.Protection:Automatically brakes/stops

1)Wire inside and outside is broken

2) The preset length is arrived

10.Brake way:Electromagnetic brake

11.Traversing method:Rolling wires with ring drive units, row pitch and breadth are adjustable

12.Operation type:push button type

13.Bobbin shifting:Manual hydraulic lifting



Pls feel free to contact us for more details,pics and videos.
