Product Details
Place of Origin: China
Brand Name: Wiremac
Certification: /
Model Number: LST-40
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD6000-10000 Unit Price
Packaging Details: L290mm×W60mm×H170mm
Delivery Time: 30 working days
Payment Terms: T/T
Supply Ability: 40 sets per month
Wire Size: |
Φ0.05-3.0mm |
Resolution: |
0.0001mm |
Accuracy: |
±0.0005mm |
Scanning Speed: |
1200n/s |
Weight: |
3KG |
Advantage: |
High Precision,intelligent |
Working Temperature: |
≤50℃ |
Wire Size: |
Φ0.05-3.0mm |
Resolution: |
0.0001mm |
Accuracy: |
±0.0005mm |
Scanning Speed: |
1200n/s |
Weight: |
3KG |
Advantage: |
High Precision,intelligent |
Working Temperature: |
≤50℃ |
Application
Online detection of extruded wire diameter.
Speficiation
1,Brand:LST
2,Wire size:Φ0.05-3.0mm
3,Resolution:0.0001mm
4,Accuracy:±0.0005mm
5,Scanning speed:1200n/s
6,Temperature:-5°C—+50°C
Feature
1,On-line measurement and control of outer diameter for any wire & cable.
2,Non-contact measurement, fast detection speed, high precision and stable performance.
3,Imported optical lens is adopted, and the influence of alloy precision diecasting, the quality is more duaranteed.
Contact us for more details,pics and videos if you are interested in.
